LMBK-L series

3D PC presentation (. Flv or. SWF)

3D Physical map

3D CAD diagram

3D CAD diagram

Mobile scanning

Product parameters

SLDPRT Download PDF Download
  • Bearing No.
    Standard type LMBK24L
    Sealed type LMBK24LUU
  • Number of steel balls 5
  • Weight (g) 1460
  • Main dimensions and tolerances (mm)
    dr 38.100
    tolerance 0/-0.015
    D 60.325
    tolerance 0/-0.022
    L 144.463
    tolerance +0.3/-0.3
  • Flange
    Df 95.250
    K 76.200
    t 12.700
    Dp 77.788
    X 8.731
    Y 12.700
    Z 8.334
  • Eccentricity μ M 25
  • Perpendicularity μ M 25
  • Rated load dynamic C (n) 3430
  • Rated load static CO (n) 8040
