LMHC series

3D PC presentation (. Flv or. SWF)

3D Physical map

3D CAD diagram

3D CAD diagram

3D Physical map

Mobile scanning

Product parameters

SLDPRT Download PDF Download
  • Nominal shaft diameter mm 16
  • LMHC LMHC16
  • Main dimensions and tolerances (mm)
    dr 16
    dr公差μm 0/-10
    D 28
    D公差μm 0/-16
    L 70
    L公差μm +300/-300
  • Flange mm
    I 32
    Df 48
    W 34
    t 6
    A 31
    F 22
    X 4.5
    Y 7.5
    Z 4.1
  • Eccentricity μ M 15
  • Perpendicularity μ M 15
  • Load ratings
    Dynamic C (n) 1230
    Static CO (n) 2350
  • Weight (g) 182

  • Request Quotation

  • *
  • *
  • *
  • *
  • *
  • *
  • Sumbit
