LMK-LTH series

3D Physical map

3D CAD diagram

3D CAD diagram

Mobile scanning

Product parameters

SLDPRT Download PDF Download
  • model
    Synthetic resin retainer LMK12LUU-TH
    Number of steel ball columns 6
    Weight (g) 85
  • Main dimensions and tolerances (mm)
    dr 12
    tolerance 0~-0.010
    D 19
    tolerance 0~-0.016
    L 57
    tolerance +-0.3
  • Main dimensions and tolerances (mm) flange
    Df 38
    K 29
    t 6
    Dp 30
    X 4.5
    Y 7.5
    Z 3.85
  • Eccentricity (um) 15
  • Vertical difference (um) 15
  • Rated load
    C(N) 605
    Co(N) 900
  • model LMK12L

  • Request Quotation

  • *
  • *
  • *
  • *
  • *
  • *
  • Sumbit
